| Certificate | ATEX, IECEx , CE, RoHS |
| Classification | Group II IIB ,Zone 1 &21 and 2&22 |
| Ex Mark | Ex d eb, Ex tb |
| IP Grade | IP66 |
| Rated power | 18W/36W/48W/56W/72W Emergency:5W |
| Voltage | 220-240 VAC/ 311-339 VDC |
| Ambient Temperature | -20℃-+55℃ |
| Luminaire Efficacy | Up to 140lm/w |
| Power factor | >0.98 |
| THD | <10% |
| Battery Type | Ni-Cd |
| Battery Lifespan | 300 cycles |
| Back up | 120 min |
| Chargeing tme: (after full discharge) |
12 hours |
| Weight | 2.3 Kg |
| Size | 223*95*233mm |
| Enclosure | Copper-free Aluminium |
| Color | Orange,RAL2011(optional grey RAL7040) |
| Protective cover | Tempered glass, stand 7J impact |
| Cable Entry | M20*1.5,M25*1.5,3/4 NPT |
The Swordfish series consist of 2 sizes : 600*136*124mm(18W/36W/48W) / 900*136*124mm(36W/48W/56W/72W),can be widely used for hazardous area Zone 1&2 ,Zone 2&22 where flammable vapors, gases,ignitable dusts, fibers or flyings are present;
Designed for use in oil and gas (including offshore), chemical, mining, pulp & paper and other hazardous environments.
Our sealion installed in Malaysia Petronas-Chemical Ethylene Project provides clear and efficient illumination.
Focus on security and energy-saving, Carry brightness and Sustainable future.
